PM8N | 8″ Midbass Speaker, 400W Max Power, 2″ Voice Coil, Neodymium Magnet

The PM8N 8″ Midbass Speaker is engineered for high-performance audio applications, delivering exceptional clarity and power in a compact design. With a 400W max power rating and a 200W RMS power handling, this speaker is perfect for car audio systems, professional sound setups, and custom enclosures. Its 2″ (50.8mm) CCAW voice coil ensures durability and consistent performance under heavy loads.

Built with a lightweight neodymium magnet and a die-cast aluminum basket, the PM8N combines durability with efficient heat dissipation. Its paper cone and cloth surround offer precise midbass response with a frequency range of 68Hz to 7.5kHz, while the 92.6dB sensitivity ensures efficient sound output. Advanced T-S parameters, including a BL Product of 8.09 and a Qts of 0.46, make it highly compatible with various enclosure designs.

At just 1.55kg, the PM8N is lightweight and easy to install, making it an ideal choice for audiophiles and professionals seeking a reliable, high-quality midbass speaker.

Inquiry Now
SKU: 33022051233-1-1 Category:
Description
Overall Dimensions mm 211*100
RMS POWER W 200
MAX POWER W 400
Sensitivity dB 92.6
Frequency Response Hz 68-7.5K
Voice Coil Diameter mm 50.8
Nominal Impedance ohms 4
DC Resistance ohms 3.5
Magnet（OZ） Neodymium
Basket material Die-Cast Aluminum Basket
Coil Material CCAW
Former material TBH
Cone Material Paper
Surround material cloth
Voice coil winding height mm 14
Gap height mm 8
Xmax mm 3
BL Product N.A 8.09
Net weight kg 1.55
Fs Hz 68
Mms g 22.3
Cms mm/N 0.24
Qms 5.77
Qes 0.51
Qts 0.46
Vas L 15.1
Sd c㎡ 208.6
No % 0.9
All specifications subject to change without notice!

Applications(Available with 8″ 10″ 12″):

  • Professional PA Systems: Ideal for live sound reinforcement and professional venues requiring powerful midbass performance.
  • Automotive Audio Systems: Enhances car audio with precise and impactful midbass response.
  • Home Theater Systems: Adds depth and clarity to home audio systems for an immersive experience.
  • Studio Monitors: Provides accurate midrange reproduction for professional sound engineering.
  • Custom Audio Projects: Perfect for designers and audio enthusiasts creating bespoke sound solutions.

Key Features:

1. Power and Performance:

  • RMS Power Handling: 200W
  • Max Power Handling: 400W for dynamic peaks.
  • Sensitivity: 92.6dB ensures efficient sound output.

2. Wide Frequency Response:

  • Range: 68Hz – 7.5kHz for rich, accurate midbass tones.

3. High-Quality Components:

  • Voice Coil:
    • Diameter: 2″ (50.8mm).
    • Material: CCAW (Copper-Clad Aluminum Wire) for lightweight durability.
    • Former Material: TBH for high thermal resistance.
  • Magnet: Neodymium for lightweight yet powerful magnetic strength.
  • Cone Material: Paper for natural and precise sound reproduction.
  • Surround Material: Cloth for improved cone movement and durability.

4. Advanced T-S Parameters:

  • Mechanical Q Factor (Qms): 5.77 for optimal cone control.
  • Electrical Q Factor (Qes): 0.51 for efficient electrical performance.
  • Total Q Factor (Qts): 0.46 for balanced sound output.
  • BL Product: 8.09 for strong magnetic strength.
  • VAS: 15.1 liters for excellent enclosure compatibility.

5. Rugged and Lightweight Design:

  • Basket Material: Die-cast aluminum for durability and heat dissipation.
  • Overall Dimensions: 211mm x 100mm for compact installations.
  • Weight: 1.55kg for easy handling and portability.

Why Choose the Audio Yong PM8N?

  1. High Performance: Built to deliver impactful and accurate midbass tones in various professional and custom audio applications.
  2. Durable Construction: Sturdy materials such as a die-cast aluminum basket and a paper cone ensure reliability under heavy use.
  3. Versatility: Compatible with multiple setups, including professional PA systems, car audio, and home theaters.
  4. Efficient Design: Features a lightweight yet powerful neodymium magnet system to reduce weight without compromising performance.
  5. OEM/Wholesale Options: Customizable solutions for businesses, including branding and bulk purchasing.

B2B & Wholesale Purchase Information:

  • Bulk Discounts: Attractive pricing for distributors and bulk buyers.
  • Custom Branding: OEM options available to incorporate your branding and specifications.
  • Global Shipping: Reliable and efficient shipping solutions tailored for international buyers.
  • Dedicated Support: Comprehensive technical support for integration and customization.

Key Applications:

  • Professional sound reinforcement
  • Automotive sound upgrades
  • Home theater systems
  • High-end studio monitors
  • Custom-built audio systems
B2B Purchasing Process

Step 1: Contact Us

Reach out to us via our website, email, or phone to share your purchasing requirements, including product types, quantities, and any branding or customization needs.

We are a company specializing in wholesale business and do not accept retail orders. Our minimum order quantities are as follows:

  • Subwoofers: Minimum order quantity of 250 units
  • Car speakers: Minimum order quantity of 300 pairs
  • Car amplifiers: Minimum order quantity of 500 units

Pricing is determined based on the order quantity and will be quoted by our customer service team. Since our primary clients are businesses with their own brand or those looking to establish their brand, prices are not displayed directly on the website. Thank you for your understanding!


Step 2: Discussion and Confirmation

Our sales team will get in touch with you promptly to understand your specific needs and provide an initial quotation. If customization is required, we can offer professional advice, including product design and technical support.

Step 3: Order Confirmation

Once the order details are finalized, we will issue a formal contract and invoice, specifying all order details, including pricing, delivery time, and logistics arrangements.

Step 4: Payment and Production

After receiving the required deposit as per the contract, we will proceed with production. The production timeline depends on the order quantity and product type and will be clearly stated in the contract.

Step 5: Delivery and After-Sales Support

Once production is complete, we will ship the products using the logistics method specified by the client and provide necessary after-sales support.

Shipping & Delivery

1. Determine Shipping Methods

Select the appropriate shipping method based on customer requirements and order volume:

  • International Shipping:
    • Sea Freight: Best for large orders, offering lower costs but longer transit times.
    • Air Freight: Suitable for small, time-sensitive orders or high-value products, though more expensive.
    • Express Delivery: Services like DHL, FedEx, and UPS are ideal for samples or urgent shipments.
  • Domestic Shipping:
    • Use local logistics providers for truck or rail transport, or opt for express couriers.
    • Choose cost-effective, time-efficient shipping services based on the delivery location.

2. Decide on Shipping Costs

Set flexible payment terms for shipping costs based on customer type and agreement:

  • FOB (Free on Board):
    Suppliers are responsible for delivering goods to the specified port, while customers handle the freight from the port to their destination. Suitable for customers with established logistics networks.
  • CIF (Cost, Insurance, and Freight):
    Suppliers cover freight and insurance costs to the destination port. Ideal for smaller clients who prefer reduced shipping complexity.
  • EXW (Ex Works):
    Customers handle all shipping costs and risks starting from the supplier’s factory. This option works well for clients with their own freight forwarders.

3. Partner with Reliable Logistics Providers

Collaborate with professional logistics companies or freight forwarders:

  • Key Criteria for Selection:
    • Timeliness: Ensure goods are delivered within the agreed timeframe.
    • Coverage: Logistics providers should cover the customer’s destination country or region.
    • Transparent Pricing: Provide clear and competitive rates without hidden charges.
    • Insurance: Offer freight insurance to safeguard against transit risks.
  • Recommended Partners:
    • International Couriers: DHL, FedEx, UPS
    • Sea Freight Forwarders: Maersk, COSCO, CMA CGM
    • Local Logistics Providers: Select dependable local companies based on the delivery region.

4. Packaging and Shipping Safety

Ensure products are well-protected during transit:

  • Packaging Standards:
    • Use sturdy cartons, wooden crates, or pallets for packaging.
    • Add protective materials like foam or bubble wrap for fragile items.
    • Clearly label the packaging with product details, quantity, weight, and shipping marks.
  • Freight Insurance:
    • For large orders, recommend freight insurance to protect against potential losses or damages during transit.

5. Provide a Clear Shipping Process and Support

  • Customer Choice of Shipping Method:
    Offer multiple shipping options for customers to choose from based on their budget and delivery timeline.
  • Real-Time Tracking:
    Provide tracking numbers and updates in coordination with logistics providers.
  • After-Sales Support:
    If issues such as delays or damages occur during transit, communicate with customers promptly and offer solutions.

6. Manage Customs Clearance

For international shipping, ensure smooth customs clearance:

  • Prepare Documentation:
    • Commercial Invoice
    • Packing List
    • Certificate of Origin (if required)
    • Bill of Lading
  • Assist with Customs:
    • Support customers in resolving customs-related issues.
    • Advise clients to familiarize themselves with local import duties and regulations.
