Audio Yong SE8V1 8" Subwoofer | 800W Dual 4Ω Coils

Description

General Data			Unit
Overall Dimensions		214*144	mm
Nominal Power Handling		400	W
Transient Power 10ms		800	W
Sensitivity		81.9	dB
Frequency Response		53-300	Hz
Cone Material		paper
Net Weight		6.27	kg
Electrical Data
Nominal Impedance		Dual 4.0	Ohm
DC Resistance		Dual 3.2	Ohm
Voice Coil and Magnet Parameters
Voice Coil Diameter		61.1	mm
Voice Coil Height		35	mm
HE Magnetic Gap Height		8	mm
Max.Linear Excursion		13.5	mm
Voice Coil bobbin		Black Aluminium
Voice Coil Wire		Copper
Number Of Layers		4	layers
Magnet System Type		High Flux Ferrite
BL Product		9.2	N.A
T-S Parameters
Suspension Compliance	Cms	0.081
Mechanical Q Factor	Qms	5.25
Electrical Q Factor	Qes	0.69
Total Q Factor	Qts	0.61
Moving Mass	Mms	110.4
Eq.Cas Air Load( liters)	VAS	4.65	Liter
Resonant Frequency	Fs	53	Hz
Effective Piston Area	SD	201	cm²
NOTE:TS Measurement Connection: parallel

Product Description for 8-Inch 400W Subwoofer – Model SE8V1 D4

High-Performance SE8V1 D4 Subwoofer for Precision Sound Systems

The SE8V1 D4 8-inch subwoofer is designed for premium sound performance, tailored to meet the needs of audio equipment manufacturers, car audio wholesale suppliers, and OEM brands. With its advanced engineering and durable materials, this subwoofer delivers rich, distortion-free bass, making it an essential component for professional sound systems.

Key Features:

1. Power and Performance:

RMS Power Handling: 400W for continuous, distortion-free performance.
Peak Power Handling: 800W for dynamic sound bursts.
Frequency Response: 53Hz – 300Hz for deep, accurate bass reproduction.
Sensitivity: 81.9dB for efficient power usage.

2. High-Quality Components:

Voice Coil:
- Diameter: 61.1mm (2.4″).
- Material: Copper winding on a black aluminum bobbin for heat resistance.
- Winding Height: 35mm for enhanced power handling and durability.
Magnet System: High flux ferrite magnet for powerful, consistent performance.
Cone Material: Paper cone for natural sound reproduction.

3. Advanced T-S Parameters:

Mechanical Q Factor (Qms): 5.25 for controlled cone movement.
Electrical Q Factor (Qes): 0.69 for efficient electrical performance.
Total Q Factor (Qts): 0.61 for balanced sound output.
VAS: 4.65L for optimized enclosure compatibility.
Xmax: 13.5mm for extended cone excursion and impactful bass.

4. Flexible Wiring Options:

Dual 4Ω Voice Coils: Enables multiple wiring configurations for amplifier compatibility.

5. Durable and Compact Design:

Basket Material: Sturdy construction for long-lasting performance.
Weight: 6.27kg for reliable and robust operation.
Dimensions: Compact size (214mm x 144mm) for versatile installation.

T-S Parameters for Precision Tuning:

Resonant Frequency (Fs): 53Hz
Suspension Compliance (Cms): 0.081
Effective Piston Area (Sd): 201 cm²
Equivalent Air Volume (Vas): 4.65L

These advanced parameters make the SE8V1 D4 easily adaptable for custom tuning in OEM applications and professional audio setups.

Applications:

Car Audio Systems:
Perfect for car stereo suppliers and businesses offering reliable and high-performance audio solutions for vehicles.
Professional Sound Installations:
Tailored for amplifier manufacturers and audio product manufacturers seeking premium-quality subwoofers.
Custom OEM Solutions:
Designed for brands looking to expand or establish their presence in the competitive audio wholesale market.

Why Choose the SE8V1 D4 Subwoofer?

Tailored for B2B Clients:
- Specifically developed for audio equipment manufacturers, car audio wholesale suppliers, and OEM brands.
Unmatched Performance:
- Offers industry-leading features such as a high-flux ferrite magnet, dual 4-ohm impedance, and advanced T-S parameters for seamless integration.
Customizable Solutions:
- OEM branding options available for audio wholesale suppliers and amplifier factories to help establish or enhance your brand.

B2B Purchase Information:

MOQ:
- Subwoofers: 250 units
Custom Branding:
- Tailored solutions for businesses with their own brand or those looking to launch a new product line.
Pricing:
- Contact our sales team for a customized quote based on your order quantity.

Let the SE8V1 D4 subwoofer elevate your product lineup with its exceptional performance and unmatched quality. Contact us today to discuss your B2B requirements or request a quote for bulk orders.
