AD350.1 | 350W Monoblock Amplifier by Audio Yong

Description

Specification	AD350.1 (Monoblock Amplifier)
Type	Monoblock Car Amplifier
Class	D
Bridgeable	No
Strappable	No
Fuse Rating	30 Amp
MOSFET Type	High Speed MOSFET Power Supply
Damping Factor	>150
Amplifier Width	6.20″
Bass EQ (Boost)	Yes (0, +6 dB, +12 dB)
Output Channels	1
RCA Line Output	No
Turn-On Circuit	Soft Turn-on Circuit
Working Voltage	8.5V – 16V
Amplifier Height	2.25″
Amplifier Length	7.54″
Subsonic Control	Off – 50Hz
Tri-Mode Capable	No
Frequency Response	20Hz – 250Hz
RMS Power at 1 Ohm	350 Watts x 1 Channel (14.4V)
Peak Power at 1 Ohm	375 Watts x 1 Channel (14.4V)
RMS Power at 2 Ohms	250 Watts x 1 Channel (14.4V)
RMS Power at 4 Ohms	150 Watts x 1 Channel (14.4V)
Efficiency at 4 Ohms	0.9
Protection Built-in?	Yes – 4-Way (Thermal, Voltage, Speaker, DC)
Power & Ground Inputs	4 Gauge
Signal-to-Noise Ratio	85 dB
Low Level Input (Gain)	6V – 0.2mV
Low Pass Filter (Variable)	50Hz – 220Hz
Power & Protection Indicators	Yes – LED Indicators
Remote Bass Knob & Cable Included	Yes

Applications

Versatile Vehicle Audio: Perfect for powering subwoofers in cars, trucks, and SUVs, from daily drivers to custom builds.
Competition-Grade Systems: Optimize bass output for SPL contests with robust power delivery.
Fleet Upgrades: Enhance audio in commercial vehicles with a durable Class D amplifier built for the long haul.

Key Features

Powerful Output: Rated at 350W RMS at 1-ohm, this monoblock amplifier can push beyond 400W at max power, ideal for driving a single 400W RMS subwoofer or a pair at 200W RMS each.
Class D Efficiency: Utilizes high-speed MOSFET power supply and an advanced PCB layout for maximum efficiency and minimal heat generation.
Customizable Controls: Features a user-friendly control panel with variable gain, low-pass filter, subsonic filter, and a bass EQ switch (0, +6, +12dB) for tailored sound.
Compact & Durable: Designed with 4-gauge power/ground terminals for optimal current flow, plus 4-way protection circuitry (thermal, short circuit, over-voltage, low-voltage) for lasting performance.

Why Choose Audio Yong’s AD350.1 Amplifier?

Unrivaled Reliability: Built with premium components, this Class D amplifier ensures consistent power delivery, making it a trusted choice for B2B clients.
Enhanced User Control: Includes a remote bass knob for real-time adjustments, giving your clients full control over their bass from the driver’s seat.
Bulk-Ready for B2B: Available with a minimum order quantity (contact us for details), perfect for large-scale car audio projects with Audio Yong.

Elevate your B2B offerings with the AD350.1 monoblock amplifier by Audio Yong—where compact design meets colossal sound!
