6.5 Inch Mid Range Speaker 300W | MC6C D4 Car Door Speaker

Description

General Data			Unit
Overall Dimensions		168*66	mm
Nominal Power Handling		80	W
Transient Power 10ms		160	W
Sensitivity		89.5	dB
Frequency Response		120-14K	Hz
Cone Material		Fiber Cone
Net Weight		1.3	kg
Electrical Data
Nominal Impedance		4	Ohm
DC Resistance		3.2	Ohm
Voice Coil and Magnet Parameters
Voice Coil Diameter		25.9	mm
Voice Coil Height		9.3	mm
HE Magnetic Gap Height		5	mm
Max.Linear Excursion		2.15	mm
Voice Coil bobbin		Kapton
Voice Coil Wire		CCAW
Number Of Layers		2	layers
Magnet System Type		High Flux Ferrite
BL Product		3.69	N.A
T-S Parameters
Suspension Compliance	Cms	0.167
Mechanical Q Factor	Qms	6.73
Electrical Q Factor	Qes	1.73
Total Q Factor	Qts	1.38
Moving Mass	Mms	10.47
Eq.Cas Air Load( liters)	VAS	4.58	Liter
Resonant Frequency	Fs	120	Hz
Effective Piston Area	SD	138.9	cm²

Product Description for MC6C Midrange Speaker(Available with 6″ 8″ 10″)

Introducing the MC6C Midrange Speaker, a high-performance 6-inch solution designed for professional audio systems, OEM manufacturers, and car audio distributors. Engineered with precision and built with premium materials, this midrange speaker delivers exceptional clarity and performance for demanding audio applications.

Superior Build Quality:

The MC6C D4 is designed for durability. For instance, its fiber cone ensures accurate sound reproduction, while the Kapton voice coil bobbin and CCAW wire provide excellent heat resistance. Furthermore, the high flux ferrite magnet guarantees consistent sound performance.

Advanced Features:

In addition to its robust construction, the MC6C D4 offers 2.15mm max linear excursion, ensuring precise and distortion-free sound at any volume. What’s more, its T-S parameters, including a Qts of 1.38, make it suitable for compact enclosures.

Applications:

Whether you are upgrading your car door speakers or creating a custom sound system, the MC6C D4 is a versatile and reliable choice. Its powerful midrange response enhances any audio setup, ensuring a premium listening experience.

Why Choose the MC6C Midrange Speaker?

At China Future Sound, we specialize in delivering high-quality, precision-engineered audio solutions tailored for B2B clients. The MC6C speaker is perfect for car audio distributors, audio equipment manufacturers, and professional loudspeaker manufacturers looking to incorporate advanced midrange components into their offerings. With our expertise and dedication to quality, the MC6C is a trusted choice for businesses seeking superior performance and durability.

B2B Purchasing Process

Step 1: Contact Us

Reach out to us via our website, email, or phone to share your purchasing requirements, including product types, quantities, and any branding or customization needs.

We are a company specializing in wholesale business and do not accept retail orders. Our minimum order quantities are as follows:

Subwoofers: Minimum order quantity of 250 units
Car speakers: Minimum order quantity of 300 pairs
Car amplifiers: Minimum order quantity of 500 units

Pricing is determined based on the order quantity and will be quoted by our customer service team. Since our primary clients are businesses with their own brand or those looking to establish their brand, prices are not displayed directly on the website. Thank you for your understanding!

Step 2: Discussion and Confirmation

Our sales team will get in touch with you promptly to understand your specific needs and provide an initial quotation. If customization is required, we can offer professional advice, including product design and technical support.

Step 3: Order Confirmation

Once the order details are finalized, we will issue a formal contract and invoice, specifying all order details, including pricing, delivery time, and logistics arrangements.

Step 4: Payment and Production

After receiving the required deposit as per the contract, we will proceed with production. The production timeline depends on the order quantity and product type and will be clearly stated in the contract.

Step 5: Delivery and After-Sales Support

Once production is complete, we will ship the products using the logistics method specified by the client and provide necessary after-sales support.
