Overall Dimensions | mm | 168*75 |
RMS POWER | W | 100 |
MAX POWER | W | 200 |
Sensitivity | dB | 93.2 |
Frequency Response | Hz | 98-10.6K |
Voice Coil Diameter | mm | 38.6 |
Nominal Impedance | ohms | 4 |
DC Resistance | ohms | 3.2 |
Magnet(OZ) | Ferrite | |
Basket material | Stamped Steel Basket | |
Coil Material | CCAW | |
Former material | Kapton | |
Cone Material | Paper | |
Surround material | cloth | |
Voice coil winding height | mm | 8.4 |
Gap height | mm | 6 |
Xmax | mm | 1.2 |
BL Product | N.A | 5.7 |
Net weight | kg | 1.9 |
Fs | Hz | 98 |
Mms | g | 8.3 |
Cms | mm/N | 0.31 |
Qms | 6.15 | |
Qes | 0.5 | |
Qts | 0.46 | |
Vas | L | 7.09 |
Sd | c㎡ | 126.6 |
No | % | 1.31 |
All specifications subject to change without notice! |
