Overall Dimensions | mm | 209*82 |
RMS POWER | W | 120 |
MAX POWER | W | 240 |
Sensitivity | dB | 92 |
Frequency Response | Hz | 80-10K |
Voice Coil Diameter | mm | 38.6 |
Nominal Impedance | ohms | 4 |
DC Resistance | ohms | 3.2 |
Magnet(OZ) | Ferrite | |
Basket material | Stamped Steel Basket | |
Coil Material | CCAW | |
Former material | Kapton | |
Cone Material | Paper | |
Surround material | cloth | |
Voice coil winding height | mm | 11.2 |
Gap height | mm | 6 |
Xmax | mm | 2.6 |
BL Product | N.A | 6.11 |
Net weight | kg | 2 |
Fs | Hz | 88 |
Mms | g | 17.43 |
Cms | mm/N | 0.18 |
Qms | 7.66 | |
Qes | 0.83 | |
Qts | 0.74 | |
Vas | L | 12.01 |
Sd | c㎡ | 213.8 |
No | % | 0.97 |
All specifications subject to change without notice! |
