Section 1: What is a Shallow Mount Subwoofer?
When it comes to subwoofers, shallow mounting depth is key, especially for vehicles with limited space. These subwoofers feature a slim design that allows them to fit in tighter spots where traditional models cannot. Despite their compact size, they can still deliver impressive bass performance thanks to their innovative engineering.
One major benefit of shallow-mount subwoofers is their efficiency. They require less power to achieve great bass response, making them ideal for setups where space and power are limited.
Section 2: Advantages of Our Factory’s 10-Inch Shallow Mount Subwoofers
1. Premium Materials for Durability
Our 10-inch shallow-mount subwoofers are built to last, using pressed steel baskets with vented holes for structural strength and enhanced airflow. The fiberglass cone ensures optimal rigidity while remaining lightweight, delivering consistent, high-quality bass performance. Paired with an NBR rubber surround, these materials ensure longevity and resistance to wear, even under heavy use.
2. Advanced Engineering for Superior Performance
Equipped with a high-efficiency magnet motor and FEA-optimized motor design, our subwoofers achieve exceptional precision and bass clarity. A multi-layer spider and rubber surround enhance stability, allowing for cleaner and stronger sound reproduction. Additionally, the unique cooling components ensure efficient heat dissipation, maintaining performance during extended use.
3. Powerful Sound Capabilities
The 2-inch black aluminum, four-layer copper high Xmax coils enable an excursion range of ±12mm, pushing sound output to new levels while retaining clarity. This setup delivers powerful bass without distortion, making it ideal for both casual and audiophile listeners.
4. Customization Options for OEM and Private Labels
We offer flexible customization options tailored to OEM or private-label clients. Whether you require specific branding, unique design features, or optimized performance parameters, our team can deliver solutions that align with your business needs.
5. Cost-Effective Excellence
Our factory combines competitive pricing with uncompromising quality, offering high-value subwoofers that outperform many industry standards. From material selection to final assembly, every step is optimized for efficiency and quality assurance.
Section 3: Featured Products – Our Best 10-Inch Shallow Mount Subwoofers
1. SG10F – Classic 10-Inch Shallow Mount Subwoofer
The SG10F is our factory’s iconic 10-inch shallow mount subwoofer, delivering robust performance and premium quality. Available with 8-inch, 10-inch and 12-inch, it offers flexibility for various audio setups, making it a top choice for professional speaker manufacturers, car audio distributors, and OEM clients.
Key Features:
- Powerful and Reliable Performance:
Handles 400W RMS and 800W peak power, providing impactful bass and consistent output for high-performance audio systems. - Exceptional Sensitivity and Frequency Range:
With 86.5 dB sensitivity and a wide frequency response of 35Hz to 300Hz, this subwoofer ensures precise and rich low-frequency sound, perfect for car audio wholesalers and equipment manufacturers. - Durable and Advanced Design:
Equipped with a 61.1mm aluminum voice coil with copper winding and a high-flux ferrite magnet system, it guarantees durability and optimal sound performance, even in demanding environments. - Optimized for Flexibility:
Offers Dual 4-ohm impedance, ensuring compatibility with diverse amplifier setups. This feature appeals to car amplifier wholesalers and car stereo distributors seeking versatile solutions. - Premium Build Materials:
Designed with a lightweight paper cone for agility and a durable aluminum bobbin for superior heat resistance. These materials make it ideal for professional and automotive applications.
2. SE10FG – 10-Inch 600W Max Power Shallow Mount Subwoofer
The SE10FG is an ideal solution for professional audio systems and automotive applications, offering superior performance and exceptional versatility. Available in 8-inch, 10-inch, and 12-inch sizes, it provides flexibility for different setups and markets.
Key Features:
- Powerful Performance:
Handles 250W RMS and 500W peak power, delivering dynamic bass and consistent output for professional audio systems and car audio solutions. - Wide Frequency Range:
Operating between 45Hz and 300Hz, it ensures a deep and rich low-frequency response, meeting the needs of car audio wholesalers and audio visual manufacturers. - Advanced Voice Coil Technology:
Equipped with a 50.8mm aluminum voice coil with copper winding, it provides excellent heat dissipation and reliability for demanding applications. - High-Flux Magnet System:
Features a high-flux ferrite magnet, enhancing sound precision and boosting efficiency for high-performance audio. - Durable Construction:
Built with a lightweight paper cone and sturdy aluminum bobbin, this subwoofer combines agility with durability, making it ideal for professional and automotive environments. - Dual Impedance Flexibility:
With Dual 4-ohm impedance, it offers compatibility with various amplifier configurations, making it a preferred choice for amplifier and car stereo suppliers.
Technical Highlights:
- Resonant Frequency (Fs): 45Hz
- Suspension Compliance (Cms): 0.102 mm/N
- Effective Piston Area (Sd): 330.06 cm²
- Total Q Factor (Qts): 0.87
These specifications make the SE10FG D4 highly adaptable for custom tuning and professional applications, catering to the demands of audio wholesale suppliers and OEM audio solutions.
Section 4: Behind the Scenes – How Our Factory Ensures Top Quality
At our factory, product quality is at the heart of everything we do. With nearly 30 years of experience, we have developed a robust three-stage process to ensure that every product meets the highest standards. These stages—Simulation, Prototyping, and Mass Production—are designed to guarantee precision, reliability, and customer satisfaction.
1. Simulation – Setting the Foundation for Excellence
The journey to quality begins with listening to our clients. We carefully analyze their feedback, combining it with our engineering expertise to provide professional advice that addresses potential design and manufacturing challenges.
Using 3D simulation software, we create digital prototypes that allow us to:
- Visualize the product’s appearance, structure, and functionality intuitively for both clients and internal teams.
- Identify and resolve design issues early, avoiding costly misunderstandings or production delays.
- Reduce development costs by analyzing feasibility and optimizing the design before production begins.
This meticulous simulation phase not only helps us align with client expectations but also lays the groundwork for higher-quality products.
2. Prototyping – Bridging the Gap Between Concept and Reality
After simulation, we bring the digital designs to life by creating physical prototypes. This critical stage allows us to:
- Validate performance: Ensure that the prototype meets design expectations and functions as intended.
- Optimize for mass production: Test parameters and identify areas for process improvement, ensuring smooth manufacturing.
- Enhance collaboration: Provide clients with samples to confirm alignment with their expectations and support early product promotion.
Prototyping is a vital step that not only verifies product quality but also enables client confidence and facilitates necessary adjustments before full-scale production.
3. Mass Production – Consistent Quality at Scale
In the final stage, we focus on maintaining the high standards established during simulation and prototyping. Key measures include:
- Premium Suppliers: Partnering with trusted suppliers who adhere to strict quality standards.
- Rigorous Material Inspections: Employing methods such as sampling and full inspection to ensure every batch of materials meets our requirements.
- Standardized Production Processes: Leveraging automated equipment to minimize human error and enhance precision.
- Critical Control Points: Setting up monitoring systems along production lines to quickly detect and address issues.
By combining advanced automation and stringent quality control, we ensure that every product rolling off the line delivers consistent performance and meets customer expectations.
Section 5: Why Choose Us as Your Subwoofer Supplier?
- Nearly 30 Years of Expertise: Proven reliability and deep industry knowledge.
- Customer-Focused Service: Dedicated support for every brand we work with.
- Flexible MOQs: Ideal for clients starting their own brand or scaling their business.
